DY-0318-1DCE
Direct Drive Heavy Duty Top And Bottom Feed Lockstitch Sewing Machine With Edge Cutter And Edge Binder

Products Summary

The model is newly well developed with a patents by DEYEE for stitching medium heavy duty upholstery, bed clothes, leisure tourist products, etc; the specially designed device enables edge-cutting and edge-binding at the same time, It is designed with a wide chip chute of 53mm×110mm; it is maximum thickness to be cut is 7mm, the standard width to be cut is 8mm(the special edge-cutting width must be specified when ordering) and the standard binder is 26mm; it features higher efficiency and fine sewing quality;

Model Max sewing speed Stitch length Needle bar stroke Presser foot lift Needle size Feed dog Lubrication Servo motor
DY-0318-1DCE 2000r.p.m 0-8mm 35mm 6/13mm DP×17 18#-24# 3 Rows of teech Auto lubricated 220V/550W
